Description
Wireless standard: 802.11 b / g / n
Frequency range: 2.4GHz~2.5GHz(2400M ~ 2483.5M)
Data interface: UART / HSPI / I2C / I2S / IR Remote Contorl / GPIO / PWM
Operating voltage: 3.0 ~ 3.6v (Suggest 3.3v)
Working current: average 80mA
Operating temperature: – 40 degrees to 125 degrees
Storage temperature: room temperature
Wireless network mode: station / softAP / SoftAP + station
Security mechanisms: WPA / WPA2
Encryption type: WEP / TKIP / AES
USB to serial TTL chip: CH340G
Upgrade firmware: local serial port burn, cloud upgrade, host download burn
Network protocols: IPV4, TCP / UDP / HTTP / FTP
User Configuration: AT + instruction set, cloud server, Android / IOS APP
Applications: Home automation, sensor networks, industrial wireless control
Note:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 0.5-1cm measuring deviation due to manual measurement.
