BIQU 3D IR Filament Sensor Kits Upgrade -Detect Stuck Filament Sensor

$7.88

SKU: 32991020954 Category:

Description

Note :

We will ship the goods as soon as the order is completed because we have the goods in stock.

Advantage of the new upgraded version

The previous sensor didn’t work well with some specific filaments. The new sensor is using the optical sensor which is triggered

by a simple mechanical lever. This sensor doesn’t care about the optical properties of the filament (it can be completely invisible) and cannot die because of mechanical wear.

IR Sensor Assembly

1. Place the IR-sensor on the top of the Extruder-body and secure it with the M2x8.

2. Tighten the M2x8 screw, the sensor shouldn’t be able to move, but be careful the PCB isn’t indestructible 😉

3. Connect the cable, mind the correct orientation of the connector and wires.

4. Leave a slack behind the sensor like in the picture. Don’t create too big loop as it might interfere with the frame. If needed adjust the length by gently pulling/pushing the cable.

BIQU 3D IR Filament Sensor Kits

BIQU 3D IR Filament Sensor Kits

BIQU 3D IR Filament Sensor KitsBIQU 3D IR Filament Sensor KitsBIQU 3D IR Filament Sensor KitsBIQU 3D IR Filament Sensor Kits

BIQU 3D IR Filament Sensor KitsBIQU 3D IR Filament Sensor KitsBIQU 3D IR Filament Sensor KitsBIQU 3D IR Filament Sensor Kits

Additional information

Brand Name

BIQU

Item Type

Motherboard

Name

IR Mk3 Sensor update Sensor

Model Number

Prusa i3 mk3 3d printer filament sensor

Type

3d printer parts

Suitable for

3d printer
